13
Vapodest 50s carousel
4.2.1 Description rear view Vap 50s carousel
1 Side door for titration tank
Behind the door there is the tank for the titration acid. To open the door, push
in the handle and pull the loop.
2 Tubing duct
For the protection of the tubes
3 Connection for external compressed air connection
If available, the in-house compressed air supply can be connected here, if the
compressor included in the shipment is not connected.
4 Socket at the instrument
For the peripheral instruments (e.g. balance or laptop). When turning the Va-
podest on, the current supply is turned on as well.
5 Upper Part of Distillation System
Further description of the upper part can be found in chapter “4.4. Rear View,
upper part Vapodest”.
6 Dripping tray
Collects any drops of chemicals. If necessary, make sure to clean it.
4 Description of the equipment
