Gerhardt Vapodest 50s carousel - Description of the Tubing Connections

69
Vapodest 50s carousel
14.2.1. Description of the tubing connections
1 PTFE-tubing suction for titration liquid
2 PVC-tubing 4/7, 2,85 m
3 PVC-tubing 4/7, 2,55 m
4 PVC-tubing 4/7, 2,55 m
5 PVC-tubing 8/12, 2,60 m
6 PVC-outlet tubing 8/12, 2,00 m
7 PVC-outlet tubing 8/12, 2,00 m
8 Verprene-tubing 8/12, 1,9 m
9 Snap lid for tubings (for all tanks)
10 Level sensor with plug for "Sample waste" tank, complete
11 Level sensor with plug for chemicals reservoir tank, complete
12 Level sensor with plug for water tank, complete
13 Level sensor with plug for titration tank, complete
14 Tubing diagram
