23 Pressure Booster Repair Instructions
Pressure Booster Repair Instructions
23
- 97 -
Compression spring
Tie rod
Piston
Throttle cylinder
Plunger
Converter piston
Top plate
Plate
Displacement
sensor WS2
Pressure sensor DS3
Barrel seal
Stud bolt
Barrel
Collar screw
Valve stem
Barrel
Flange
Valve plate
Sight glass
Valve ball
Air connection
Locking socket
Cover
Compression spring
Baseplate
Ring magnet
Displacement sensor
WS1
Float
Sensor holder
Sensor
holder
Piston seal
Guide ring
Shim
Set of piston
seals
