GAV Settings
9.9 Additional Functions
Additional functions settings
The hand trigger is blocked when the function is activated.
The hand trigger can be deactivated when other start options
(foot trigger or PLC activation) were activated.
Precondition: Foot trigger connected (accessory).
The cycle is started by a foot trigger when the function is ac-
tive (start option "Foot").
Contact pressure monitor-
ing
Precondition: GAV riveting gun with contact pressure
monitoring connected (special version)
With the function activated, the blind riveting gun is pressed
against the material to be joined at a defined force to start a
cycle.
Rivet monitoring, feed hose
Precondition: Additional sensor RS2 fitted on feed hose
(accessory).
With the function activated, rivet feed is monitored and a Riv-
et check,. feed hose fault may be triggered.
Resets all settings to default.
Executes one processing cycle
(see Section 8.7 "Manual Operation" "Cycle" function).
Navigation:
AUTO
►MAN
► Menu
► GAV settings
► Additional functions
Additional functions settings
menu
