9.10 PLC Activation
GAV Settings
9.10 PLC Activation
Default
Resets all settings to default.
Cycle
Executes one processing cycle
(see Section 8.7 "Manual Operation" "Cycle" function).
PLC activation settings
PLC Activation
Precondition: PLC interface connected (accessory).
With the function activated, the PLC starts the cycle via the PLC
interface (start option "PLC"). Activation is described in detail in
Section 28 "PLC Interface".
Block hand trigger
The hand trigger is blocked when the function is activated.
The hand trigger can be deactivated when other start options (foot
trigger or PLC activation) were activated.
Rivet check, nosepiece
Precondition: PLC interface connected (accessory),
additional sensor (e.g. light barrier) installed in
nosepiece area of GAV riveting gun and
connected to PLC interface.
With the function activated, the blind rivet loading procedure in the
nosepiece of the GAV riveting gun is monitored and a Rivet
check, nosepiece fault may be triggered. Installation of the sensor
is described in Section 28 "PLC Interface".
9
- 49 -
Navigation:
AUTO
►MAN
► Menu
► GAV settings
► PLC activation
PLC activation settings menu
