Functional Principle
The fully automatic GAV electronic blind riveting system consists of a supply unit and a practical
blind riveting gun, both connected by a flexible hose assembly.
The supply unit contains an electronic controller with dialogue unit, two hydraulic pressure
boosters, an electrical blind rivet feed unit and a spent mandrel evacuation system with spent
mandrel container.
The blind rivet made set in the nosepiece is processed when the riveting gun is triggered, the
spent mandrel is conveyed into the spent mandrel container and the next rivet is loaded auto-
matically.
The task of the vibration feed unit with automatic shut-down facility is to continuously feed in the
blind rivets.
GAV blind riveting gun
