4 Transportation and Installation
4 Transportation and Installation
Transportation
Corresponding to the agreement, the blind riveting system is delivered and installed or dis-
patched upright in a special wooden container.
Left unpacked, the blind riveting system can be moved with a trolley, available as an acces-
sory, on an even floor. The blind riveting system must be transported by the two lifting eyes
on the top of the supply unit and suitable lifting gear or secured upright on a pallet by a pallet
truck or fork-lift truck.
The blind riveting system is supplied ready for connection and contains
approx. 1.2 litres of hydraulic oil in its closed hydraulic system. The
supply unit must always be transported in upright position and its stabil-
ity ensured.
Installation
Operating pressure: min. 6 bar
- The compressed air supply system must be capable of making available dried, oil-free
compressed air at a rate of 750 NL/min which must not drop below a pressure of 6 bar dur-
ing operation of the GAV device (do not use mist lubricator!).
- Pipe diameter 3/4"
The inside diameter of the compressed air supply hose must be at least
12.5 mm (1/2"). The pressure must not drop below 6 bar during the riv-
eting process; check operating pressure on pressure gauge.
Hydraulic oil: For viscosity see technical data.
Electrical connection: 230 V ~ 50 Hz, alternatively 115 V ~ 60 Hz.
