Gesipa 8000 - Cycle

9.8 Cycle
GAV Settings
9.8 Cycle
Home position ON
"ON" button function from "OFF" state.
Release time
Home position is activated on reaching the set value.
Times in cycle
Monitors and controls times in the cycle.
Stroke position monitoring time
Cycle fault on reaching the set value.
Stroke position waiting time
Cycle is stopped in stroke position until the set value is
reached.
This function can be activated under special conditions
(e.g. excessively long supply line assembly).
Return monitoring time
Cycle fault on reaching the set value.
Default
Resets all settings to default.
Cycle
Executes one processing cycle
(see Section 8.7 "Manual Operation" "Cycle" function).
Stroke
Moves riveting gun to stroke position
(see Section 8.7 "Manual Operation" "Stroke Position" function).
9
- 47 -
Navigation:
AUTO
►MAN
► Menu
► GAV settings
► Cycle
Cycle settings menu
