Overview of Assemblies
Spare Parts
Overview of Assemblies
Assembly No. Description Page
1 Pneumatics control block 3 - 4
2 Blind riveting gun, Standard 5 - 11
2-R Robotic 5-R - 11-R
2-U Overhead 5-U - 11-U
2-UA Overhead with
spring-loaded trigger 5-UA - 11-UA
3 Hydraulic booster unit 12 - 13
4 Separator 14
5 Housing unit 15
6 Vibration feed unit 16
7 Supply line assembly 17
8 Electronic controller unit 18
9 Accessories 19 - 20
10 Front panel 21
11 Wiring harness 22 - 23
11
4
6
8
3
1
5
7
10
11
2
E0
- 1 -
2-U
2-R
2-UA
