E2-U Blind Riveting Gun Overhead
Spare Parts
E2-U Blind Riveting Gun Overhead
Part No.
Component No.
Description
1434407
GAV
2 – 6000U
Blind riveting gun assy
719 7535
GAV
2 – 6001U
Housing assy
1445656
GAV
2 – 6001U7
Screw connection
1434557
GAV
2 - 2
Cover
1434495
GAV
2 - 6003
Threaded plug
1434737
GAV
2 - 6205
Jaw housing 36° (identification: 1 ring)
1434535
GAV
2 - 6005
Jaw housing 28° (identification: 2 rings)
1456909
GAV
2 - 6009 
Lock activator assy
1457004
GAV
2 - 6010
Lock activator assy, assembled
1456928
GAV
2 - 11
Closing tube assy
1457075
GAV
2 - 11.1
Closing tube assy, assembled
1434494
GAV
2 - 6012 
Cylinder sleeve
1456874
GAV
2 - 6013  
Reset piston assy with component No. 6083 + 6085
1434587
GAV
2 - 16
Casing ring
1434588
GAV
2 - 17 
Washer
1434589
GAV
2 - 18
Washer
1434590
GAV
2 - 19
Washer
1456910
GAV
2 - 6020  
Stop piston assy with component No. 2-55
1456919
GAV
2 - 6020.1 
Stop piston assy with component No. 2-55
extended by 4mm
1434517
GAV
2 - 6021
Stop ring
1434591
GAV
2 - 22
Closing sleeve
1456917
GAV
2 - 6022
Closing sleeve for spreader nosepiece 2-80/F
1434525
GAV
2 - 6023 
Feather key
1434592
GAV
2 - 24 
Slide
1457034
GAV
2 - 25 
Actuator assy
1434593
GAV
2 - 27/2
Coupling piece
1434549
GAV
2 - 27/3
Pin
1445505
GAV
2 - 27/4
Compression spring
1434677
GAV
2 - 27/5 
O-ring 8.5 x 2
1434594
GAV
2 - 28
Bleeder screw (2x)
1434595
GAV
2 - 529 
Sleeve
1456866
GAV
2 - 6030  
Driver bush assy with component No. 2-56
1434490
GAV
2 - 6031 
Stop bush
1434741
GAV
2 - 6031.1
Stop bush, shortened by 2 mm
 Included in lock activator assy No. 2-6010
 Only available as assembly
 Included in set of seals No. 2-6191
- 6-U -
E2-U
