E2-UA Blind Riveting Gun Overhead with Spring-Loaded Trigger
Spare Parts
E2-UA Blind Riveting Gun Overhead with Spring-Loaded Trigger
Part No.
Component
No.
Description
1434740
GAV
2 - 6032
Jaw tube
1434596
GAV
2 - 33
Lock spring
1456861
GAV
2 - 33 B
Lock spring (shortened by 9 mm)
1456868
GAV
2 - 33 C
Lock spring (90 notch)
1457029
GAV
2 - 33 D
Lock spring (without scoop)
1434596
GAV
2 - 35 
Compression spring
1445505
GAV
2 - 36
Compression spring
1445506
GAV
2 - 37
Hexagon socket head cap screw M5 x 12
1445507
GAV
2 - 39 
Snap ring SW 18
1434598
GAV
2 - 40 
Snap ring SW 18, shortened
1445417
GAV
2 - 6041 
Snap ring SW 20
1445508
GAV
2 - 42
Circlip SB 24
1445462
GAV
2 - 6043  
Circlip (22 x 1.5)
1445416
GAV
2 - 6044  
Snap ring SW 27
1434600
GAV
2 - 47
Grooved ring, black
1434601
GAV
2 - 48 
Grooved ring, blue  assembly tool 9-19 required,
see Accessories, Page 19 and 20
1434602
GAV
2 - 49 
Wiper
1434603
GAV
2 - 50 
O-ring 18 x 2 (4x)
1434604
GAV
2 - 51 
O-ring 24 x 2
1434605
GAV
2 - 52 
O-ring 32 x 2
1434607
GAV
2 - 54 
O-ring 3.68 x 1.78 (for 2-25) 2x
1434609
GAV
2 - 55 
O-ring 4.3 x 2.4
1434607
GAV
2 - 56 
O-ring 6 x 1
1434608
GAV
2 - 57 
USIT ring (2x)
1456929
GAV
2 - 59 
Nipple
1445661
GAV
2 - 63
Plug connection
1457064
GAV
2 - 64
Screw connection
 Included in lock activator assy No. 2-6010
 Only available as assembly
 Included in set of seals No. 2-6191
- 7-UA -
E2-UA
