E2 Blind Riveting Gun
Spare Parts
E2 Blind Riveting Gun
Item
Component
No.
Part No.
Description
69  
2-6069
1456873
Valve piston assy with component No. 6079 + 6094
70 
2-6070
1434487
Switching ring
71 
2-6071
1434485
Support ring
72  °
2-6072
1456872
Casing ring assy with component No. 6084
73  °
2-6073
1434437
Spacer ring
74 
2-6074
1434484
Stop ring
75 
2-6075
1434481
Spacer ring
76
2-6076
1434531
Washer
77
2-6077
1434533
Jaw stop ring
81  °
2-6081
1434499
O-ring 28 x 1.5 (2x)
82  °
2-6082
1434498
O-ring 26 x 3
83 °
2-6083
1434497
O-ring 16 x 2
84  °
2-6084
1434496
O-ring 10 x 2
85 °
2-6085
719 7768
O-ring 6 x 2
86 °
2-6086
1434746
O-ring 6.75 x 1.78
90 
2-6090
1445414
Compression spring
92
2-6092
1445464
Jaw spring (3x)
93 
2-6093
1445463
Leaf spring
147  °
2-6147
1434551
Grooved ring, green (2x)
150
2-6150
1457069
Nosepiece lock assy
151
2-6151
1434441
Coupling sleeve
152
2-6152
1434442
Union nut
153
2-6153
1434443
Feather key
155
2-6155
1445368
Corrugated ring
190
2-6190
1456876
Piston unit
191
2-6191
1456877
Set of seals
300
2-6300
1434678
Mandrel transfer unit
301
2-6301
1462893
Mandrel guide assy
302
2-6302
1434685
Baseplate
303
2-6303
1434686
Base
313
2-6313
1434579
Adapter
314
2-6314
1462853
Plastic hose
315
2-6315
1445566
Plug connection
321
2-6321
1457017
Mandrel guide assy
 Included in lock activator assy No. 10
 Only available as assembly
° Included in set of seals No. 191
E2
