20 Fault - Blind Riveting Gun
Fault - Blind Riveting Gun
Two blind rivets in spreader nosepiece
- Press OFF button
- Remove blind rivets
- Press ON button
- Execute "Cycle" function in "MAN" menu.
Cause
Corrective measures
Separator tongue 4-8007 maladjusted.
Adjust separator tongue 4-8007 such that only
one blind rivet at a time is separated.
A second blind rivet entered the separator after
opening the separator manually.
- Press "OFF" button.
- Remove second blind rivet.
- Press "ON" button.
The blind rivet was not conveyed up to the
nosepiece during the previous operating cycle.
Installation radius of rivet feed hose too
small.
Increase installation radius of rivet feed hose.
Rivet feed hose excessively worn.
Replace rivet feed hose.
Rivet feed hose too dry.
Refill central lubrication, see Section 10.1
"Maintenance Information" - "Refilling Central
Lubrication" and "Oiling Rivet Feed Hose".
Correct setting of central lubrication system,
see Section 9.6 "GAV Settings" - "Blow Air".
Lock spring 2-33 broken or spring rubber
detached.
Replace lock spring 2-8033, see Section 21
"Riveting Gun Repair Instructions" - "Replacing
Lock Spring".
Blow air set incorrectly.
Set blow air, for basic setting see Section 9.6
"GAV Settings" - "Blow Air".
