MDE-3664B TRIND® Start-up, Service, and Parts Manual · June 2013 Page 1-5
TRIND Kit Coverage Introduction
TRIND Kit Coverage
Following table provides TRIND kit numbers and the relative system coverage that applies to
each:
Kit Number Product Coverage Frequencies Interface Type Tag System
C00011-001 The Advantage
Series, MPD-3
LF/UH
F T20229-G1 Card Cage Hand-held/Car Mounted
C00011-002 The Advantage
Series, MPD-3
LF/UH
F (see note 2) T20606-G2 Card Cage Hand-held/Car Mounted
C00011-005 The Advantage
Series, MPD-3
LF (
see note1) T20606-G3 Card Cage Hand-held
C00011-004 Encore 500 LF/UHF T20606-G2 Card Cage Hand-held/Car Mounted
C00011-006 Encore 500, Eclipse LF T20606-G3 Card Cage Hand-held
C00011-007 The Advantage
Seri
es, MPD-3
LF/UH
F [ETSI (see note 3)] T20606-G5 Card Cage Hand-held/Car Mounted
C00011-008 Encore 500 LF/UHF (ETSI) T20606-G2 Card Cage Hand-held/Car Mounted
C00011-009 The Advantage
Series, MPD-3
LF/UH
F T20606-G5 Card Cage Hand-held/Car Mounted
C00011-010 The Advantage
Series, MPD-3
LF/UH
F T20606-G2 Card Cage Hand-held/Car Mounted
C00012-00X The Advantage
Series, MPD-3
HF (
see note 4) T20538-G1/G2 Card Cage Hand-held
Notes:
1. LF = Low Frequency [LF (134 kHz)] send and receive for Hand-held Tags.
2. LF/UHF = LF (134kHz) send, and Ultra-Hi Frequency [UHF (902 MHz)] r
eceive for C
ar Tags. LF (134 kHz) for Hand-held Tags.
3. LF/UHF (ETSI) = LF (134 kHz) send and UHF (868 MHz) receive for Car Tags. LF (134 kHz) for Hand-held Tags.
4. HF = High Frequency [HF (13.56 MHz)] send and receive for Hand-held Tags.
