Card Cage Assemblies Major Hardware Components
Card Cage Cable Harness (T20662-G2)
The Card Cage Cable Harness Assembly provides power and data distribution to/from the
Card Cage and the Light/Micro Reader Printed Circuit Assembly (PCA). It comes already
installed on the T20606-G2 Card Cage from the factory.
Figure 4-13: Card Cage Cable Harness
Full System TRIND Transmitter Cable (R20520-G1)
The Transmitter Cable is a 26-pin connector cable that is routed between the Low Frequency
Transmitter Board (Q13579) and DCB (Q13563).
Figure 4-14: Transmitter Cable
