Major Hardware Components System Cables
Page 4-40 MDE-3664B TRIND® Start-up, Service, and Parts Manual · June 2013
Hand-held System Cable Connections on The Advantage Series and MPD-3
Dispensers
For all single-sided units, install Dummy Load Connector (R20526-01) on JB on transmitter
PCB and skip all Side B connections.
Note: If power is applied to Card Cage without antenna cables or dummy load connected, the
transmitter boar
d will be damaged.
On Cable Connect To On
R20509-G2 (marked for Side A) P1/2 J1 Side A Overhead Antenna (low frequency)
PA/B *JA Transmitter PCB Q13564
R20509-G2 (unmarked for Side B) P1/2 J2 Side B Overhead Antenna (low frequency)
PA/B *JB Transmitter PCB Q13564
R20519-G1 J182 P182 Light/Micro Reader PCB Assembly T20182 on Side A Options Door
P7 *J7 DCB PCB Q13563
R20519-G2 J182 P182 Light/Micro Reader PCB Assembly T20182 on Side B Options Door
P8 *J8 DCB PCB Q13563
R20521-G1 J180 P180 Light/Micro Reader PCB Assembly T20182 on Side A Options Door
J177 *P177 Power Supply PCB T20138
GRD *Ground
stud
Card Cage
R20521-G2 J180 P180 Light/Micro Reader PCB Assembly T20182 on Side B Options Door
J176 *P176 Power Supply PCB T20138
GRD *Ground
stud
Card Cage
Q13578-01 -01 (marked for Side A) P1 J1 Side A Overhead Antenna (HF)
P1 *J2B Receive PCB
Q13578-01 (unmarked for Side B) P1 J2 Side B Overhead Antenna (HF)
P1 *J2A Receive PCB
R20437-G01 J250 *P250 TI Gateway PCB T20128-G1
J258A P258 Side A CRIND Logic PCB T17764
J258B P258 Side B CRIND Logic PCB T17764
R20580-G1 (per unit) 3 prong F 3 prong M Card Cage, Rear
Notes:
1. *Indicates connection point is on Card Cage assembly.
2. Route R20521-G1, R20521-G2, and R20437-G01 Cables through
bottom of Car
d Cage to Side B for connections.
3. Check whether brand panel lighting ballast is connected to power supply
. If so, disconnect ballast from power supply and terminate wires
ends according to NFPA 70, the National Electric Code and applicable local codes.
To Next Page
