MDE-3664B TRIND® Start-up, Service, and Parts Manual · June 2013 Page 4-41
System Cables Major Hardware Components
Full System Cable Connections on Encore 500 Dispensers
For all single-sided units, Dummy Load Connector (R20526-01) is installed on JB on
transmitter PCB and eliminates all Side B connections.
Note: If power is applied to Card Cage without antenna cables or dummy load connected the
transmitter boar
d will be damaged.
On Cable Connect To On
M00515A002 J3110 P3110 CRIND Control Node PCA M00089
J250 P250 Gateway PCB T20678
M00878A001 PA JA Transmitter PCB Q13579-01
PB JB Transmitter PCB Q13579-01
P1A J1 Side A Low Frequency Overhead Antenna
P1B J1 Side B Low Frequency Overhead Antenna
P2A J2A UHF Receive PCB Q13564
P2B J2B UHF Receive PCB Q13564
P3A J2 Side A High Frequency Overhead Antenna
P3B J2 Side B High Frequency Overhead Antenna
M00811A001 P1 J1 M00806A001 Power Distribution Cable
3 Prong M P3 3 Prong F, R20206 Power Input Cable
R20509-G2 (marked for Side A) P1/2 J1 Side A Overhead Antenna (LF)
PA/B *JA Transmitter PCB Q13564
R20509-G2 (unmarked for Side B) P1/2 J2 Side B Overhead Antenna (LF)
PA/B *JB Transmitter PCB Q13564
R20519-G1 J182 P182 Light/Micro Reader PCB Assembly T20182 on Side A Options Door
P7 *J7 DCB PCB Q13563
R20519-G2 J182 P182 Light/Micro Reader PCB Assembly T20182 on Side B Options Door
P8 *J8 DCB PCB Q13563
R20521-G1 J180 P180 Light/Micro Reader PCB Assembly T20182 on Side A Options Door
J177 *P177 Power supply PCB T20138
GRD *Ground stud Card Cage
R20521-G2 J180 P180 Light/Micro Reader PCB Assembly T20182 on Side B Options Door
J176 *P176 Power supply PCB T20138
GRD *Ground stud Card Cage
Q13578 01-01 (marked for Side A) P1 J1 Side A Overhead Antenna (HF)
P1 *J2B Receive PCB
Q13578-01 (unmarked for Side B) P1 J2 Side B Overhead Antenna (HF)
P1 *J2A Receive PCB
R20437-G01 J250 *P250 TI Gateway PCB T20128-G1
J258A P258 Side A CRIND Logic PCB T17764
J258B P258 Side B CRIND Logic PCB T17764
R20580-G1 (per unit) 3 prong F 3 prong M Card Cage, Rear
Notes:
1. *Indicates connection point is on Card Cage assembly.
2. Route R20521-G1, R20521-G2, and R20437-G01 Cables through
bottom of Car
d Cage to Side B for connections.
3. Check whether brand panel lighting ballast is connected to power supply. If so, disconnect ballast fro
m power supply and terminate wires
ends according to NFPA 70, the National Electric Code and applicable local codes.
