Card Cage Assemblies Major Hardware Components
Hand-held TRIND System Ribbon Cable (M00507)
The Ribbon Cable is a 14-pin cable routed between T12678 Gateway Board and R20773
TRIND Option Door Data and Power Cable. The R20773 Cable leads to the Light/Micro
Reader Board (T20601). The -A001 Cable is used for Side A (or Side 1 based on the
dispenser). The -A002 Cable is used for Side B (or Side 2 based on the dispenser).
Figure 4-17: Hand-held TRIND System Ribbon Cable
Hand-held TRIND System Power Cable (M01366)
The TRIND Power Cable is a three-wire cable routed between the T20314 Power Supply
Assembly and the T20678 Gateway Board.
Figure 4-18: Hand-held TRIND System Power Cable
