Procedures for Factory Installed TRIND Positioning Overhead Antennas
Page 6-2 MDE-3664B TRIND® Start-up, Service, and Parts Manual · June 2013
4 Slide the antenna back towards the unit until the bolts stops in the slots and the molded part of
the antenna bracket is secure inside the bracket fork.
Note: Before tightening the bolts, ensure that the ca
bles coming from the antenna are securely
positioned inside the stamped groove part of the bracket and are not trapped under the
bracket.
5 Tighten the bolts that secure the antenna into position using the 3/8-inch nut driver or
equivalent.
