golmar NEXA Series User Manual

WIRING DIAGRAMS
142
AUDIO AND VIDEO DOOR ENTRY SYSTEM - CODED PANEL WITH DISPLAY
Continued from previous page
C2NC1 NC2
CN1
P
~ ~
C1NA1 NA2
PL1 PL2
-
CN8
PL2
PL1
SEC
~~
PRI
~~
SEC
~~
PRI
~~
(*)
Va.c
(*)
Va.c
CN3
LINE2
2300
SEC
PRI
CN4
SE+ LINESE-
(*)
Use the varistor supplied if using anAC lock release directly on the terminals of the lock release.
N3301
access control module
FA-Gtwin
power supply unit
Door panels with
GTWINEL632 sound module
TF-104
transformer
TF-104
transformer
Main
Main Main
