AUDIO AND VIDEO DOOR ENTRY SYSTEM WITH NEXA CODED PANEL
INTRODUCTION
First and foremost we would like to thank you for purchasing this product.
Our commitment to satisfying our customers can be seen from our ISO-9001 certification and from the manufacturing of
products like this one.
Its advanced technology and exacting quality control will ensure that customers and users enjoy the many features this
system offers. To obtain the maximum benefit from these features and a properly wired installation, we kindly
recommend that you spend a few minutes of your time reading this manual.
MOUNTING CONFIGURATIONS
2
Standalone access control........................................................................................................................................ ....5. .
Access control combined with Nexa door panels...........................................................................................................23.
Coded panel.................................................................................................................................................................54.
Coded panel with display.............................................................................................................................................. 98.
SET-UP WARNINGS
- Do not overtighten the screws on the power supply connector.
- Always disconnect the power supplybefore installing or making modifications to the devices.
- The fitting and handling of these devices must be carried out by .authorised personnel
- The wiring must run at least .40cm away from any other wiring
- Before connecting the device, check the connections between the door panel, power supply, distributors, monitors
and telephones.
- Always follow the instructions contained in this manual.
SAFETY PRECAUTIONS
- Do not overtighten the screws on the door panel connector.
- before installing or making modifications to the device.Always disconnect the power supply
- The fitting and handling of these devices must be carried out by .authorised personnel
- The wiring must run at least .40cm away from any other wiring
- For the power supply
Do not overtighten the screws on the connector.
Install the power supply in a dry and protected place free from the risk of water leaks or sprays.
Avoid locations that are humid, dusty or near heat sources.
Ensure that the air vents are free from obstruction so that air can circulate freely.
To prevent damage, the power supply must be firmly secured in place.
To prevent electric shock, do not remove the cover or handle the wiring connected to the terminals.
- For the monitor, telephones and distributors:
Do not overtighten the screws on the connector.
Install the devices in a dry protected location free from the risk of dripping or splashing water.
Do not place in humid, dusty or smoky locations, or near sources of heat.
Ensure that the air vents are free from obstruction so that air can circulate freely.
- Remember that the installation and handling of these devices must be performed by and in theauthorised personnel
absence of electrical current.
- Always follow the instructions contained in this manual.
