Firmware Version 1.0.3.30

GXV3240 User Guide

Page 44 of 177

Bluetooth is enabled but not connected.

Bluetooth headset is connected.

Bluetooth headset is being used for calls.

Downloading files via Bluetooth.

Alarm is set up and enabled.

DND is enabled.

Mute is enabled.

Silent mode is enabled. When it's on, the incoming call/message

won't produce ring tone/notification tone from phone's speaker.

SD Card is inserted.

SD Card space full.

USB flash drive is inserted.

Downloading files via Internet connection.

Updating applications.

Calendar has event scheduled.

New voicemail to be retrieved.

Unread Email to be retrieved.
