"Type"
In this column you can select if the control setting for this channel
has to act globally "G" or according to the phase "PH". If the control
has to be assigned specifically to the phase, the related phase must
be active. In the second line from the bottom of the display will be
shown the phase name.
"fr"
Here you can assign the desired proportional control. If no control is
assigned, it will be displayed "fr" (free). Here you can assign propor-
tional controls only, no switch. Assign a control by pushing the SET
button and actuate the desired control. It will appear the abbrevia-
tion of the selected control.
"SEL "
Here you can assign the desired switch. If a proportional control is
already assigned, it will be deactivated and you will be able to assign
a second switch in the column. Ta again on SET, you can also assign
logical switches or normal switches.
Assign a switch by pushing the SET button and actuate the desired
switch. It will appear the abbreviation of the selected switch.
Delete proportional control or switch:
• Use the SET button to select the desired field
• Tap on the selection buttons
t u or  at the same time
"Offset"
Here, move the center of the channel in a possible range from -125%
to + 125%.
Symmetrical travel setting:
Move the related control element (control stick, proportional con-
trol or switch) into a position in which both sides of the travel adjust-
ment are surrounded by the marking frame. Set with the SET button
and the selection buttons.
Asymmetrical travel setting:
Move the related control element (control stick, proportional con-
trol or switch) into a position in which the single side of the travel
adjustment is surrounded by the marking frame. Set with the SET
button and the selection buttons.
In5
offset
0%
0%
0%
–––
0%
In6
In7
In8
–––
–––
–––
GL
GL
GL
GL
typ
Normal
fr
fr
fr
fr
SEL
In5
offset
0%
0%
0%
–––
0%
In6
In7
In8
–––
–––
–––
GL
GL
GL
GL
typ
Normal
fr
fr
fr
fr
SEL
Move desired
control adj.
In5
offset
0%
0%
0%
–––
0%
E6
E7
E8
–––
–––
–––
GL
GL
GL
GL
typ
Normal
fr
SD2
fr
fr
SEL
Move desired switch
to ON position
(ext. switch: SET)
In5
offset
0%
0%
0%
–––
0%
In6
In7
In8
–––
–––
GL
GL
GL
GL
typ
Normal
fr
fr
fr
