Update through USB port
Download the actual software package from the Internet, and
unpack it on your computer. Connect your switched off transmitter
with your PC, by using the included USB cable, which is supplied with
the package content, plug USB cable directly to the micro USB port
of the transmitter and the other end to a free port in your computer.
All other information can be found in the instructions that come in
the software package.
Problems during firmware update
Problem: POWER switch without function
If a firmware update for the transmitter is unsuccessful or the trans-
mitter program freezes and the transmitter cannot be turned off
using the "POWER" switch, then remove the transmitter's battery
after setting the switch to "POWER = OFF" position, or pull the plug
from the transmitter battery, reconnect it after few seconds and
leave the transmitter switched OFF.
Download the actual update file from internet and save it in the
"RECOVERY" folder in your SD card. The change the file name in
"R280.bin".
Insert the SD card in the transmitter.
Push and hold the Ctl 5 and Ctl 6 buttons at the same time to the top
and push the POWER button.
Now push and hold to the lower side within 2 - 3 seconds the Ctl 5
and Ctl 6 for about 10 seconds.
Wait then at least 30 seconds. In the display will be shown no image.
During the update the transmitter cannot be switched on.
After 30 seconds the transmitter switches on.
Declaration of conformity
S1033 / S1036 / 33028 - mc-26 / mc-28 / mc-28 4D
Graupner/SJ declares that the product is conform to EU norms.
EMV 2004/108/EC:
EN 301 489-1 V1.9.2
EN 301 489-17 V2.1.1
EN 62479:2010
LVD 2006/95/EC:
EN 60950-1 + A11 + A1 + A12 + A2:2013
R&TTE 1999/5/EC:
EN 300 328 V1.8.1
EN 62311:2008
