Throttle curve (Heli)
The setting of the curve is explained in the previous description of
the menu "Throttle curve". Note that the curve characteristic set
here acts as an input signal on mixers of the "Helicopter mix" menu.
Sticks setting (Heli)
The setting of the column is explained in the previous description of
the menu "Stick settings". The setting variants are tailored to the
needs of helicopter models, so in the line "Throttle", after activating
the selection field with the selection buttons, you can switch
between:
"TH"(Throttle limit)
The Throttle trim functions as an idle trim when the "Throttle limit"
function is used to control the motor for starting, see the menu
"Control setting".
"AR"(Throttle-autorotation)
The throttle trim functions acts as an idle trim exclusively in the
"Autorot" phase. This means that the AR throttle position, which is
fixed in the "Helicopter mix" menu, can be "varied" with the idle
trim, for example during autorotation exercises.
Control adjust (Heli)
In this menu, three additional settings are possible for the model
selection "Heli".
Channel 6 - Throttle
In contrast to a fixed-wing aircraft, the throttle servo or the speed
controller of a helicopter is not directly controlled by the stick or
another control but through a complex mixing system, see menu
"Heli mix". In addition, the "Throttle limiter function
" also has an
influence on this mixing system.
Servo adjustment
Stick mode
Switch display
Control adjust
Dual Rate / Expo
Channel 1 curve
»Heli-Mischer«
K1
K-1-
Kurve
Pitch
Gas
Pitch-
Knüppel
Servo adjustment
Dual Rate / Expo
Stick mode
Channel 1 curve
Switch display
Control adjust
Thr.
Roll
Nick
Tr
+
time
4
4
4
0.0s
0.0s
0.0s
4
0.0s
Tail
0.0s
0.0s
0.0s
0.0s
TL
PH
PH
St
PH
In5
Offset
0%
0%
0%
–––
0%
Thro
Gyro
In8
–––
–––
–––
GL
GL
GL
GL
typ
Normal
fr
fr
fr
fr
SEL
