Receiver binding
You can bind two receivers to the transmitter. The two bound receiv-
ers can be also managed in this option. You can split the control
channels of the receivers in the "Receiver output" as you prefer.
Binding process
Move to the "n/v" field near the "HoTT" field through the selection
buttons. Set your HoTT receivers in the binding mode. The binding
method is different for the different types of receiver, see the follow-
ing table.
1. Set the receiver in the binding mode
1st binding
method
Push and hold the binding button
Receiver type GR-12
green LED on
= bound
GR-12L
red LED off =
bound
GR-18/24
green LED on
= bound
2nd binding
method
Push and hold the button until the LED blinks
red/green
Receiver type GR-16 / 24 / 32 - green LED on = bound
3rd binding
method
No binding button, the receiver enters auto-
matically the binding mode after switching on
Receiver type Gr-10C, GR-12 SC / SH
red LED off = bound
2. Tap now on the SET button, a "BIND" info window will appear.
If the binding process has been successful in the left field it appears
now "bound". In the line "Receiver output" appears now under the
"bound" field the identification of the receiver (e.g. E12 = GR-24). It
also appears BD1 and BD2 in the lowest line of the display. The mean-
ing of the message will be cleared in the "Telemetry menu" section.
Note
If the binding process was not successful, verify the following condi-
tions:
 Is the distance between transmitter and receiver at least 50 cm?
 Is the power source of the receiver OK?
 Is the polarity of the power supply correct?
 Was the binding button correctly pushed?
If you want to bind a second receiver, then proceed as described
before. Move therefore first to the right "n/v" field.
Mod. name
Stick mode
1
n/a
Base setup model
GRAUBELE
Rcv Ch Map
n/a
Module
HoTT
n/a
n/a
Mod. name
Stick mode
1
n/a
Base setup model
bind
BD1
GRAUBELE
BD2
Rcv Ch Map R12
n/a
Module
HoTT
