the selection key  over the "Timer" column to the right side.
The timer defined as "stopwatch" or "motor runtime" adds the
switch-on time. If you do not enter a value in the "Timer" column,
the timer counts up. If you set a value, the timer counts backward
from this value.
Through the buttons
t u or  of the right touch-pad you can
reset the timer in the basic display to "0:00h".
In the "Alarm" column, you can specify a time at which an audible
alarm is emitted. You can reach the column by moving the marking
frame with the selection key  over the "Timer" column to the right
side.
When the set time has elapsed, the announcement will sound "zero"
and the timer will be highlighted in the basic display. This function is
only available when the timer is backwards.
Log-time (Log-time - Total flight time)
When you set this timer, the telemetry data is logged on the SD card.
All other functions are like the "Stop / Motor" timers.
Use example
Default: "Stopwatch" and "Log timer" should be started simultane-
ously via the CH1 stick (throttle stick) as soon as a defined switching
point is exceeded.
Solution: For this purpose, a "G1" switch is first defined in the "Con-
trol switch" menu.
Change in the "Control switch" menu. In line G1, press the SET but-
ton and then move your throttle stick to the desired switch point
position.
Select the column STO, tap on the SET button and the position will
be stored.
The control switch "G1" is then assigned in teh "Timer" (general)
menu. To do this, in the "Log-timer" and "Stop" lines on the far right
of the "
" column assign the "G1" switch (tap 3x the SET button).
The stopwatch is now stopped below the switching point and con-
tinues above the switching point. The log timer can only be stopped
by pressing the ESC key when the stopwatch is stopped.
Model time
Batt. time
Top:
Centr:Log t.
Alarm
–––
12:34h
1:23h
0s
0s
Stop
C1
SEL
C1
