In a series switch of mixers, the direct control signal of the channel
is not used as the input of the mixer but the already mixed signal of
the channel from the upstream mixer.
P : This option also includes the trim values from the "Phase trim"
menu of the input channel as a function of the phase.
Notice
In the case of series switch, note that the mixing travel of the indi-
vidual mixers add together with simultaneous stick movement. As a
result, the servo or the servos may mechanically collide. In order to
prevent this, the "servo travel" must be reduced or a corresponding
"travel limit" in the "Servo adjustment" menu should be set and / or
the mixing value should be reduced.
"From"
Channels 1 to 16, in case of model type "Airplane" the channels 1 to
4 are marked Thr (throttle), AILE (ailerons), ELE (elevator), RUDD
(rudder)
„S“ = Switch channel - to the mixer input is assigned a constant input
signal with the assigned switch. The value of the signal is set in the
display page of the column "
".
"To"
In the input field of this column you can input the target of the mixer,
which means the mixer output, to one of the control channels.
“ “
In this column you can assign a switch or control switch. Through this
switch you can activate or deactivate the mixer.
Setting the linear mixers M1 … M8
Open the display page in the column "
". When you move the
control of the mixer input, you move a vertical line in the graphic
to the right of the display. This line shows the actual position of the
control. In the line under "Mix input" set the travel of the mixer
output. If "SYM" is selected in the bottom line, the two values
change symmetrically (simultaneously). If you select "ASY" (asym-
metric), you can change the values separately. Each time the values
are changed, the position of the horizontal line changes. This line
shows the travel of the mixer output.
L.Mix1
0%
0%
0%
Offset
ASY
SYM
1
Mix input
3
To Next Page
