ELE -> FLAP (ELEVATOR -> FLAP)
To support the elevator, the flap function can be influenced by the
elevator control in a phase-specific manner with this mixer. Select
the mixing directionto move the flaps downward when the elevator
is pulled ("up"), and conversely upward when the elevator is pushed
("down"). A symmetrical or an asymmetrical effect can be defined
for each flap pair. Set the respective control in the middle or the
respective side. Values of ±150% are possible. With a switch assigned
in the next line "ELE -> FLAP Offset", the deployment of the flaps from
the elevator and the range of the deployment can be switched off
and on and also set.
ELE -> FLAP Offset (symmetrical elevator Offset)
In the previously described line "ELE -> FLAP", you have entered a
value to support the elevator. In this line "HR -> WK Offset", you
determine the "application point" of the proportionate entrainment
of the flaps from the elevator through the offset value. The flaps are
entrained from the elevator from the neutral position of the elevator
control stick with the percentage set in the line "ELE -> FLAP" and
with an offset value of 0%, .
With an offset value not equal to 0%, the flaps are only entrained
from the specified offset point in the direction "low" and in the direc-
tion "high" during a movement of the elevator control stick.
To adjust the offset point, bring the elevator control stick to the
desired position in one of the two possible directions. Tap the SET
button to store this position, regardless of the current position of the
elevator trim. Push the SET button in the center position of the ele-
vator control to set the offset value back to 0%, regardless of the cur-
rent position of the elevator trim.
The deployment of the flaps from the elevator can be switched off
and on with a switch assigned in the “Switch” column. Assigning a
switch is described in the section "Control and switch assignment".
FL
0%
0%
FL pos.
EL FL 0%0%
0%
AI
Normal
Diff.
0%
FL
0%
0%
FL pos.
EL FL 0%0%
0%
STO
Normal
EL FL Off.
0%
–––
