Channel 7 - Gyro
Current gyro systems can be adjusted for a smooth, proportional
effect. You can also choose between two different modes of action
with the transmitter.
If the Gyro has this option, specify "Normal" Gyro action and "Head-
ing Lock operation" in the "Offset" column in the range of ± 125%.
You can fly with maximum stabilization in normal, slow fights within
this selected mode, and reducethe gyro gain in fast roundtrips and
aerobatics.
Take advantage of switching phases to enter different settings in the
"gyro" line.
Please read the instructions of the related gyro system.
Channel 16 - Limit
After the initialization of a new model memory with the model type
"helicopter", the input "Lim." is "free" as standard from factory.
The option “throttle limit” can be activated and set again by assign-
ing a control, for example, the right-hand proportional slide control
SD2, .
The "throttle limit" function acts to limit the position of the throttle
servo or the speed controller of a motor control unit.
In5
Offset
0%
0%
0%
–––
0%
Thro
Gyro
In8
–––
–––
–––
GL
GL
GL
GL
typ
Normal
fr
fr
fr
fr
SEL
In15
Offset
In13
In14
Lim.
–––
–––
–––
0%
0%
0%
0%
GL
GL
GL
GL
typ
fr
fr
fr
–––
SEL
fr
Normal

GRAUPNER MC-28 Specifications

General

Proper use	Helicopter
Product type	Remote control
Product color	Black, Silver
Frequency band	2.4 - 2.484 GHz
Menu languages	DEU, DUT, ENG, ESP, FRE, ITA
Channels quantity	16 channels
Brand compatibility	Graupner
Throttle (TH) function	Yes
Compatible memory cards	MicroSD (TransFlash)
Number of memory records	120
Maximum operating distance	3000 m
Operating temperature (T-T)	-15 - 55 °C
Power consumption (charging)	400 mA
Operating voltage (max)	4.35 V
Operating voltage (min)	3.4 V

Weight and Dimensions

Depth	235 mm
Width	228 mm
Height	66 mm
Weight	1250 g
