GreenWorks CU800 - Page 128

MALFUNCTION INSPECTION CU800 Service Manual
121
No.
Part Name
Qty
Remarks
18
Bed Door Locks
2
19
Rubber Washer Φ13×10
4
20
Handle Rubber Sleeve
2
21
Bed Door
1
22
Hinge Plate, Bed
2
23
Hexagon Flange Bolt M8×12
2
24
Plastic Turnup Liner Φ10.5×Φ18
2
25
lock pin, Cargo
2
26
Insulation Plate,Taillight Line
1
27
Insulation Board, Muffler
1
28
Hexagon Flange Bolt M6×16
6
29
R Type Pin B
2
30
Split Pin Φ12×47
2
31
Hexagon Flange Locking Nut M8
2
Cargo Bed
