MALFUNCTION INSPECTION CU800 Service Manual
122
No.
Part Name
Qty
Remarks
Removing the cargo bed
1
Cargo Bed
1
2
Front Board, Bed
1
3
Nut Holder M6×2
33
4
Cross Large Plate Head Screw M6×16
4
5
Left Board Of Bed (Black)
1
Left Board Of Bed (Yellow Camo Vista)
1
6
Right Board Of Bed (Black)
1
Right Board Of Bed (Yellow Camo Vista)
1
7
Socket Hexagon Screw M6×20
6
8
Cross Large Plate Head Screw M6×16
18
No.
Part Name
Qty
Remarks
9
Hexagon Flange Nut M6
2
