GreenWorks CU800 - Page 130

MALFUNCTION INSPECTION CU800 Service Manual
123
10
Front Fence Assy, Bed
1
Front Fence Assy, Bed：GLB Green
1
11
Side Fence Assy, Bed
2
Side Fence Assy, Bed：GLB Green
2
12
Hexagon Flange Bolt M8×16
10
13
Rear Left Wheel Regula Ii
1
14
Rear Right Wheel Regula Ii
1
15
Strip Hook
4
16
Cross Large Plate Head Screw M6×16
8
17
Inner Scaleboard, Cargo Door
1
18
Socket Hexagon Screw M6×16
6
No.
Part Name
Qty
Remarks
19
Support Plate,Bed Door
1
20
Bed Door Panel
1
21
Door Switch Comb.,Cargo Bed
1
