MALFUNCTION INSPECTION CU800 Service Manual
127
No.
Part Name
Qty
Remarks
Removing the steering wheel
1
Steering Wheel Assy
1
2
Fixed Cap, Steering Wheel
1
3
Socket Hexagon Screw M5×20
6
4
Insulation Plate, Horn I
1
6
Lower Cover I
1
7
Steering Gear Assy
1
8
Deep Groove Ball Bearing 6003-2RZ
1
9
Direction Driveshaft Assy
1
10
Deep Groove Ball Bearing 6805
1
