MALFUNCTION INSPECTION CU800 Service Manual
128
No.
Part Name
Qty
Remarks
11
Ignition switch assy.
1
12
Earth Conductor, Horn
1
13
Hydraumatic Spring Assy
1
14
Step slotting pin Φ8×34
1
15
Washer 5
2
16
Steering Column
1
17
Hexagon flange bolt M10×1.25×16
3
18
Step Bolts M6×Φ10×2.5×30.5
2
19
Hexagon Flange Locked Nut M6
2
20
Pin Φ8×45
1
21
Lower Cover Ⅲ ,Ignition Switch
1
22
Steering column cover Ⅱ
1
23
Socket Hexagon Screw M6×12
2
