MALFUNCTION INSPECTION CU800 Service Manual
129
No.
Part Name
Qty
Remarks
24
Cross Recessed Pan Head Tapping
Screw St3.9×13
3
25
Direction Driveshaft Assembly
1
26
Hexagon bolt with flange M8×30
1
27
Steering Gear Ball Joint
2
28
Hexagon Thin Slotted Nut M14×1.5
2
29
Pin 2×30
2
30
Hexagon Flange Bolt M10×1.25×35
4
31
Gasket 10×32×5
3
32
Spring washer Φ10
3
33
Plain washer Φ10
2
34
Spring Washer Φ10
2
35
Insulation Plate, horn Ii
1
36
Connecting Cap , Steering wheel
1
37
Connecting Plate, Horn
1
38
Spring, Horn
1
39
Cross Plate Head Tapping Screw M4
×8
1
40
Hexagon Flange Lock Nut M12×1.25
1
