MALFUNCTION INSPECTION CU800 Service Manual
137
Disk Brake Components
No.
Part Name
Qty
Remarks
Removing brake components
1
Hydraulic Brake Subassembly Ⅰ
1
2
Line brake (front/right)
1
3
Line brake (front/left)
1
4
Disc brake pliers assembly(front/right)
1
5
Disc brake pliers assembly(front/left)
1
6
Disc (front/left)
2
7
Roof Bar, Disc Brake
1
8
Hexagon flange bolt M10×1.25×22
8
9
Gasket, Oil Pipe
19
