MALFUNCTION INSPECTION CU800 Service Manual
138
No.
Part Name
Qty
Remarks
10
Oil Pipe BoltⅠ
7
11
ClipⅠ,Oil Pipe
7
12
Hexagon Flange Bolt M6×16
10
13
Main Brake Bump Assembly
1
14
Line brake (rear/right)
1
15
Bolt hexagon flange head M8×25
2
16
Line brake (rear/left)
1
17
Hexagon Flange Bolt M12×1.25×155
2
18
Oil Pipe Bolt Ii,Hydraulic Pressure
1
19
Middle Oil Pipe
1
20
disc (front/left)
1
21
Disc(front/right)
1
