MALFUNCTION INSPECTION CU800 Service Manual
149
Rear Wheels
No.
Part Name
Qty
Remarks
Removing the rear wheel
1
Rear Hub
2
2
Rear Tire(28*11-14)
2
3
Valve Core
2
4
Nut M10×1.25
8
5
Trim Cover G, Hub
2
6
Hexagon Slotted Nut M24×1.5
2
7
Mounting Bracket ,Rear Hub
2
9
Inner Hexagon Cone Step Bolt M8
8
10
Cotter Pin 3.2×50
2
