MALFUNCTION INSPECTION CU800 Service Manual
150
WARNING
Securely support the vehicle so there is no
danger of falling over.
5.4.1 Checking the Wheel Tire
1. Check:
• wheel tire
2. Measure:
• wheel runout
Over the specified limit Replace the
wheel or check the wheel bearing play ①.
3. Check:
• wheel balance
Out of balance Adjust.
Wheel runout limit
Radial ②: 2.0 mm (0.08 in)
Lateral ③: 2.0 mm (0.08 in)
WARNING
The profile depth falls below 3mm, Please
replace the tire immediately.
• tire wear limit ⓐ
5.4.2 Checking the Wheel Hub
1. Check:
• wheel hub ①
Cracks/damage Replace.
• splines (wheel hub) ②
Wear/damage Replace.
• nuts (wheel hub)
loosen or distorted Replace or tighten
