GreenWorks CU800 - Page 158

MALFUNCTION INSPECTION CU800 Service Manual
151
5.4.3 Installing the Wheel Hub
1. Install:
• axle nut
260 Nm (26.0 m · kg, 190 ft · lb)
5.4.4 Installing the Wheel TIRE
1. Install:
• wheel
NOTE
The arrow mark ① on the tire must point in
the direction of rotation A of the wheel.
2. Tighten:
• wheel nuts ①
WARNING
Tapered wheel nuts ① are used for both the
front and rear wheels. Install each nut.
The angle of the conical bores is 60°
