GreenWorks CU800 - Page 161

MALFUNCTION INSPECTION CU800 Service Manual
154
Front Bridge
No.
Part Name
Qty
Remarks
Removing the front bridge
1
Front Differential Assy
1
2
Front Axle Gear Box Cover
1
3
O-type ring Φ 140× Φ 2.65
1
4
Deep Groove Ball Bearing φ35×φ62
×9
1
5
Circlip D0=62
1
6
Divide Device Connection
1
7
Sliding Sleeve
1
8
Adjustment Gasket Φ 71× Φ 83×0.1
1
9
Deep Groove Ball Bearing 61912
1
10
Transfer Gear
1
