GreenWorks CU800 - Page 162

MALFUNCTION INSPECTION CU800 Service Manual
155
No.
Part Name
Qty
Remarks
11
Bevel Gear，Front Axle
1
12
Anti-Rotation Gasket
1
13
Adjustment Gasket Φ40×Φ57×0.1
1
14
Drive & Driven Gears Assy, Front Axle
1
15
Deep Groove Ball Bearing 6007
1
16
Adjustment GasketⅠΦ50×Φ61.5
1
17
Front Axle Gear Box
1
18
Bolt M10×1.25×16
6
19
Plain Washer Φ10
6
20
Front Diff. Output Shaft Oil Sealφ24×
Φ38×8
1
21
Front Diff. Output Shaft Oil Sealφ24×
Φ38×8
1
