GreenWorks CU800 - Page 163

MALFUNCTION INSPECTION CU800 Service Manual
156
No.
Part Name
Qty
Remarks
22
Needle Bearing Φ15×Φ21×12
1
23
Spring Washer Φ10
4
24
Deep Groove Ball Bearing 6007
1
25
Circlip D0=62
1
26
Oil Seal Φ48×Φ65×9, Driving Tooth
1
27
O-Ring Φ14×Φ7 , Driving Tooth
1
28
Hexagon Flange Locked Nut M14×1.5
1
29
Bolt M14×1.5×10
1
30
Rubber O-Ring Φ12.5×Φ1.5
1
31
Hexagon Flange Bolt M10×1.25×16
1
32
Oil Drain Plug O-Ring φ1.5×φ9
1
