GreenWorks CU800 - Page 164

MALFUNCTION INSPECTION CU800 Service Manual
157
No.
Part Name
Qty
Remarks
33
Hexagon Flange Bolt M8×25
6
34
Air Tap, Rear Axle
1
35
Inner Hexagon Screw With Flat Head M8×10
1
36
Cylindrical Pin Φ5×75
1
37
Fork
1
38
Spline
1
39
O-Ring Φ81×Φ2
1
40
Transfer Case Assembly
1
41
Hexagon Socket Cap Screw M8×20
3
42
Plain Washer 8
4
43
Connection Fork H
1
