GreenWorks CU800 - Page 167

MALFUNCTION INSPECTION CU800 Service Manual
160
Front Transmission Axle Assy
No.
Part Name
Qty
Remarks
Transmission Axle knock down
1
Front Bridge Drive Shaft Assy
1
2
Transmission Shaft Dust Cover
1
3
Pain Washer A
8
4
Cir clip D0=25
2
5
Front Transmission Shaft R
1
6
Pressure Spring B,Drive Shaft
2
7
Transmission Shaft Dust Cover B
1
8
Connection Fork C
5
9
Cross-Shaped Component
3
10
C-type Washer(φ20)
12
