GreenWorks CU800 - Page 168

MALFUNCTION INSPECTION CU800 Service Manual
161
No.
Part Name
Qty
Remarks
11
Cir clip D0=24
2
12
Cir clip D0=25
4
13
Oil Seal φ25×φ42×7
4
14
Ball Bearing 6205-2Rs
2
15
Transmission Bearing House
2
16
Hexagon Flange Bolt M6×20
4
17
Hexagon Flange Bolt M8×25
4
18
Front Drive Shaft T
1
19
Rear Drive Shaft S
1
20
Connection Fork L
1
21
Front Bridge Middle Drive Shaft Assy
1
22
Front Bridge Rear Drive Shaft Assy
1
