MALFUNCTION INSPECTION CU800 Service Manual
167
No.
Part Name
Qty
Remarks
Removing the rear bridge reducer
1
Oil Seal ∅38×∅58×8
1
2
End Cap
1
3
Steel Magnet
2
4
O-Ring 16.4×2.2
2
5
Front Bridge Oil Outer Bolt
2
6
Woodruff Key 6×9×22
1
7
Rear diff driven gear
1
8
Rear axle active gear
1
Taper rear axle driving gear (old
condition)
Taper rear axle driving gear (old condition)
•
•
Taper rear axle driving gear (old condition)
•
Taper rear axle driving gear (old condition)
•
Taper rear axle driving gear (old condition)
•
Rear axle active gear
1
Spline rear axle drive gear
9
Transfer Case
1
10
Cushion Cover Ⅱ
1
11
30207 Bearing35×72×18.25
2
12
Oil Seal ∅35×∅52×7
2
13
Hexagon Flange Bolt M8×30-C
8
14
Rear Axle Gear Box Cover
1
15
Hexagon Flange Bolt M8×40-C
8
16
Transfer Gear
1
17
Rear Axle Gear Box
1
18
Oil Sealφ30×φ45×7
1
19
Clip E
3
20
Rear Diff Air Fitting
1
21
Locating Sleeve
4
22
6206RS Bearing30×62×16
2
23
Idler Gear
1
24
Driving Bevel Wheel
1
25
6305RS Bearingφ25×φ62×17
2
26
Adjustment Gasket ∅50×∅61.5
2
27
6306RS Bearing30×72×19
1
28
O-Ring 26×2.7
1
29
Oil Seal Sleeve Ⅱ
1
30
Cushion CoverⅠ
1
31
Rear Bridge Oil Inner Bolt
1
32
O-Ring 16.4×2.2
1
33
Hexagon Flange Bolt M8×45-C
17
34
Anti-Rotation Gasket
1
35
Round Nut
1
36
Dash Cover
1
