MALFUNCTION INSPECTION CU800 Service Manual
168
37
Joint Plate
1
Conical flange (old condition)
Joint Plate
1
Spline flange
38
Socket Hexagon Screw M6×15
4
39
Plain Washerφ14.5×φ35.2×4
1
40
Hexagon Flange Locked Nut M14×1.5
1
41
Rear Axle Assy
1
Cone(old condition)
Rear Axle Assy
1
Spline
42
Line fuel
1
43
Connector
1
44
Airbag
1
45
Adjusting Spacer ∅68×∅79.5
2
46
Adjusting Spacer ∅27.3×∅40×1
1
47
Oil Mirror
1
48
Adjusting Spacer ∅62×∅71.5
2
(The service method of the rear bridge parts is the same as the front bridge parts, please refer
to the before-mentioned to operate.)
NOTE:
Apply lithium-soap-based grease to the bearing assembly and O-ring and bearing and driven
gear and oil seal and drive shaft coupling and final drive pinion gear bearing housing.
