MALFUNCTION INSPECTION CU800 Service Manual
169
Footrest
No.
Part Name
Qty
Remarks
FOOTREST
1
Front Fender
1
2
ClipⅠ, Oil Pipe
1
3
Hexagon Flange Nut M6
2
4
Hexagon Flange Bolt M6×16
2
5
Hexagon Flange Bolt M10×1.25×55
1
6
Hexagon Flange Locked Nut M10×1.25
1
7
Brake Pedal
1
8
Footrest
1
9
Torsional Spring J
1
